MOZA Racing CS Pro Steering Wheel

MOZA CS PRO STEERING WHEEL
PRODUCT OVERVIEW
The MOZA CS Pro is a comprehensive racing wheel designed for competitive racing and future expandability. Featuring a 325mm standard rim, carbon fiber-reinforced construction, and a customizable high-definition display, it delivers precise control and fast feedback. Its "golden ratio" layout ensures that all buttons and dials are within easy reach, providing comfort even during long-stint sessions.
KEY FEATURES
● Customizable UI Display: A 2.99-inch high-definition screen that allows for extensive UI personalization via MOZA Pit House software.
● Carbon Fiber Reinforced Construction: Hub made from lightweight composite material to minimize fatigue and sharpen force feedback response.
● Swappable Wheel Rim: Industry-standard 6x70 bolt pattern, making the button box compatible with most 3rd party rims, including drift rims.
● Fully Customizable Lighting: Features 10 RGB rev lights, 6 side-mounted flag lights (Yellow, Blue, Red), and 4 RGB rotary switches with 16.7 million colors.
● Forged Carbon Magnetic Shifters: Next-gen paddle module with Hall sensors for ultimate precision. Supports dual-clutch or programmable input modes.
● Optional 6-Paddle Upgrade: Pre-installed mounting points for additional paddles to control DRS, KERS, or other complex vehicle settings.
● Extensive Input Control: Packed with 8 RGB buttons, 4 twelve-position rotary encoders, 2 seven-way funky switches, and 2 thumbwheels.
● Aerospace-Grade Quick Release: All-aluminum system modeled after real race cars for fast, secure, and stable wheel swaps.
TECHNICAL SPECIFICATIONS
● Dimensions: 325mm (Standard Rim)
● Material: Carbon fiber-reinforced composite (Front & Back Plate)
● Frame Material: Aluminum Alloy
● Grip Material: Eco-friendly Microfiber Leather
● Display: 2.99-inch High-Definition Screen
● Buttons: 8 Backlit Short-Travel RGB Buttons + 2 Rear Buttons
● Encoders: 4 Rotary Encoders + 2 Thumb Encoders
● Switches: 2 Seven-Way Funky Switches
● LED Indicators: 10 Rev Lights & 6 Flag Lights (16.7M Colors)
● Paddles: Magnetic Forged Carbon with Hall Sensors (Dual-clutch supported)
● Communication: Wired via Conductive Slip Ring
● Compatibility: All MOZA bases & 3rd party bases (via MOZA hub kit)
